Reviewed by Mike Shellim (c. 2002)Version 1 of John Garnham's airfoil package was simple but a little lacking in features. For Version 2, Frankie Arzu has provided the extra features which makes this a thoroughly useful and flexible little program. FeaturesFourteen sections are provided, including RG series, S3021, E193 and SD7032 & SD7037. These are in Compufoil (.COR) format. The following attributes can be specified for a profile:.
Airfoil Programs
Chord selection. Leading edge thickness. Skin thickness. Template height and lead-in. WashoutThe following are new in version 2:. Multi-page printing. Text information on the printing,.
Wire keft compensation. Station Lines.Complete profiles are saved as as.PRO files, which store all the attributes of an airfoil including section, chord etc. In UseThe About box says 'the application is so simple that no online help has been included'.
Airfoil Programs
Which sums it up nicely.The program is ideal for producing foam templates, especially now that it has wire kerf compensation and station lines. This is what most people use plotting programs for these days, anyway.The new version will split large sections over multiple pages, so really large sections are possible. Cross-hairs are printed to allow sheets to be joined accurately.No tests were made for accuracy, but the printed results looked fine on my Laserjet 4.What doesn't it do? Foam volume calculation, graduated plots and spar drawing are not supported - if this is a problem then you'll need have something like Compufoil Pro. Download(on this site) PRO'S.
Very simple to use. Good support for templates for foam cutting. Version 2 has useful new features. FreewareCONS. Not suitable for plotting graduated rib sets. Cannot print spars.
